Lenovo SR868 Server-Spezifikation |
|
Formfaktor | 4U |
Verarbeiter | 2 oder 4 Intel Xeon-Prozessor der zweiten Generation Skalierbare CPU-Familie, bis zu 165 W |
Gedächtnis | Bis zu 6 TB in 48x-Slots (mit 4x-CPUs) unter Verwendung von 128GB-DIMMs; 2666MHz / 2933MHz TruDDR4 |
Erweiterung | bis zu 11x PCIe plus 1x LOM; optional 1x ML2-Slot |
Innenspeicher | bis zu 16x 2,5" Speicherräume mit Unterstützung von SAS/SATA-HDDs und SSDs oder bis zu 8x 2,5" NVMe-SSDs; plus bis zu 2x gespiegelter M.2-Boot |
Netzwerkoberfläche | Mehrfache Optionen mit 1GbE-, 10GbE-, 25GbE-, 32GbE-, 40GbE- oder InfiniBand-PCIe-Adaptern; eine (2-/4-Port) 1GbE- oder 10GbE-LOM-Karte |
Unterstützung der GPU | Bis zu 2x unterstützte GPUs |
Macht | 2x Hot-Swap/redundant: 750W/1100W/1600W/2000 AC 80 PLUS Platin |
Sicherheit und Verfügbarkeit | TPM 1,2 bis 2.0PFA; Hot-Swap/Redundant-Antriebe und PSUs; Redundante Ventilatoren; interne Lichtbahndiagnostik-LEDs; Front-Access-Diagnostik über dedizierten USB-Anschluss; optionale diagnostische LCD-Paneele |
RAID-Unterstützung | HW RAID (bis zu 16 Ports) mit Flash-Cache; bis zu 16 Ports HBAs |
Systemmanagement | XClarity Controller eingebettetes Management, XClarity Administrator zentralisierte Infrastrukturbereitstellung, XClarity Integrator Plugins und XClarity Energy Manager zentralisiertes Server-Strommanagement |
Unterstützung des Betriebssystems | Microsoft, Red Hat, SUSE und VMware. |
